Microcrystalline Mica Ceramic Capacitor

Product Overview

The Microcrystalline Mica Ceramic Capacitor is made from high-quality microcrystalline mica ceramic material, offering a high dielectric constant and stable operational characteristics, which makes it suitable for use in high-voltage electrical equipment. This capacitor is designed to withstand high voltages and lightning surges, making it ideal for various high-voltage electrical systems. It features low partial discharge, high voltage tolerance, and a wide temperature operating range, ensuring long life and reliability for electrical devices.

Features

• High Voltage Tolerance: Capable of withstanding up to 50kV AC, ensuring stable operation in high-voltage environments.
• Lightning Surge Protection: Designed to withstand lightning surges up to 90kV, providing additional safety protection.
• Low Partial Discharge: At 20kV, partial discharge is less than 3pC, minimizing interference and damage to the system.
• Stable Temperature Characteristics: Operates with a temperature change rate of less than 3% in the range of -40°C to +70°C, ensuring stability in diverse environmental conditions.
• High Dielectric Constant: With a dielectric constant of 320, the capacitor offers superior energy storage capacity and electrical performance.
• Wide Operating Temperature Range: Operates effectively in temperatures ranging from -55°C to +125°C, making it suitable for extreme environments.

Applications

• High Voltage Electrical Equipment: Widely used in high-voltage electrical systems, such as substations and distribution equipment, for voltage stabilization and protection.
• Power Transformers: Applied in power transformers for voltage regulation and filtering, enhancing the stability of the power system.
• Lightning Protection: Used in lightning protection systems, designed to withstand lightning strikes and protect electrical equipment from damage.
• High-Frequency Circuits: Suitable for high-frequency circuits that require high stability and low partial discharge, such as communication equipment, radar systems, etc.
• Industrial and Research Applications: Used in various industrial devices and research projects to provide stable energy storage and regulation functions.
