High Toughened PA6 (High Toughness Nylon 6) provides optimized impact resistance, superior mechanical strength, and enhanced durability. Designed for automotive components, industrial applications, and structural parts, it ensures long-term performance, lightweight efficiency, and high adaptability.
Product Overview
High Toughened PA6 is a modified Nylon 6 material with enhanced toughness, extremely low moisture absorption, and exceptional impact resistance and flowability. This material is particularly suitable for applications that require high toughness and excellent processability, maintaining good physical properties even under complex working conditions.
Key Features
- Low Moisture Absorption: Maintains stable physical properties even in damp environments, adaptable to various climatic conditions.
- High Impact Strength: The toughened design significantly improves impact resistance, making it ideal for applications where the material is exposed to impact and pressure.
- Good Flowability: Excellent flowability ensures smooth injection molding, facilitating the filling of complex mold shapes and shortening molding cycles.
- High Strength and Durability: Exhibits outstanding mechanical strength and long-term stability, ensuring reliable performance in harsh working environments.
Applications
High Toughened PA6 is suitable for applications requiring high toughness, durability, and ease of processing:
- Electronics and Electrical Components: Primarily used in the production of impact-resistant and stable electronic components and electrical parts.
- Machined Parts: Ideal for producing mechanical components that demand high toughness and wear resistance.
- Automotive Parts: Widely used in automotive applications such as engine components, interior parts, and structural components.
- Sports Equipment: Suitable for manufacturing sports equipment and accessories requiring high toughness and impact resistance.
Test Item | Unit | Test Method | Test Condition | Typical Values |
Physical Property | ||||
Density | g/cm³ | ISO 1183 | - | 1.06 |
Filler Content | % | ISO 1172 | - | - |
Mold Shrinkage | % | ISO 294 | Parallel 1.2, Vertical 1.6 | - |
Mechanical Property | ||||
Tensile Strength | MPa | ISO 527 | I-type sample, 50mm/min | 45 |
Elongation at Break | % | ISO 527 | I-type sample, 50mm/min, Gauge 50mm | 50 |
Flexural Strength | MPa | ISO 178 | 23℃, 10mm/min | 55 |
Flexural Modulus | MPa | ISO 178 | 23℃, 10mm/min | 1750 |
Izod Impact Strength (Notched) | KJ/m² | ISO 180 | 23℃ | 58 |
Charpy Impact Strength (Unnotched) | KJ/m² | ISO 179 | 23℃ | NB |
Thermal Property | ||||
Melting Point | ℃ | ISO 11357-1 | - | 220 |
Heat Deflection Temperature | ℃ | ISO 75 | 0.45MPA 120℃, 1.8MPA 50℃ | 120, 50 |
Flammability | ||||
Flammability Class | UL-94 | - | HB | |
Glow Wire Ignition Temperature | ℃ | IEC 60695-2-13 | - | - |
Electrical Property | ||||
Surface Resistivity | Ω | IEC 60093 | - | 100000000000000 |
Volume Resistivity | Ω•cm | IEC 60093 | - | 1000000000000000 |
