Power Online Monitoring Equipment

Product Overview

This series of Power Online Monitoring Equipment is designed using the capacitor voltage divider principle for high-voltage signal acquisition and measurement. The equipment is characterized by high accuracy and is suitable for operation in environments ranging from -40°C to +85°C, ensuring stable performance even under extreme conditions. High-voltage ceramic capacitors collect voltage signals, while low-voltage ceramic capacitors divide the voltage, enabling precise acquisition of low-voltage signals. The device is compact and easy to install in spaces with limited room.

Features

• High-Precision Measurement: Uses the high-precision capacitor voltage divider principle to ensure accurate voltage signal acquisition and measurement.
• Wide Operating Temperature Range: Designed to operate stably in temperatures ranging from -40°C to +85°C.
• High Voltage Endurance: Supports various voltage ratings including 10KV, 20KV, and 35KV, and has strong resistance to impulse voltages (80/120/210KV).
• High-Frequency Stability: Made with Class I electronic ceramic materials, ensuring stable performance in high-frequency environments.
• Compact Miniaturized Design: Small-sized equipment suitable for installation in tight spaces.
• Customizable Low Voltage Output: Offers flexible low voltage signal output options to meet different needs.

Applications

• High-Voltage Power Systems: Used for online monitoring and data collection in power lines and high-voltage power equipment.
• Smart Grids: Used for real-time monitoring of voltage fluctuations and equipment status in smart grids.
• Power Automation: Applied in power automation systems for signal acquisition and power quality monitoring.
• Power Equipment Maintenance: Provides continuous online monitoring for power transformers, switchgear, and other equipment to ensure stable operation.
• Renewable Energy Field: Used in wind, solar, and other renewable energy power generation systems for power quality monitoring.
