Carrier communication couplers facilitate high-speed signal transmission, optimized impedance matching, and reliable data integration. Designed for industrial and grid applications, they enhance communication efficiency, ensure stable operation, and support advanced networking protocols.
Product Overview
The Carrier Communication Coupler Series Capacitors are designed to meet the high-frequency and high-voltage demands of power carrier communication systems. These capacitors offer low loss, high capacitance, and high-frequency characteristics. They can be used in different frequency bands such as KHz, MHz, and GHz for power carrier communication, effectively supporting data transmission and ensuring the stability and efficiency of power systems. The products have strong load capacity, good anti-interference performance, small size, and large capacitance, making them suitable for various power communication frequency bands. Users can select the appropriate material and capacitance based on specific needs to ensure optimal system performance.
Features
- High-frequency Performance: Suitable for a wide frequency range of 10KHz to 5GHz, meeting different communication requirements.
- High Voltage Resistance: Rated voltage up to 10kVAC, withstands 42KVAC for 2 minutes, suitable for high-voltage power systems.
- Low Loss: Tangent of loss angle ≤0.01%, ensuring minimal energy loss and improved communication efficiency.
- Strong Anti-interference: Excellent anti-interference capability and stability, suitable for harsh power environments.
- Large Capacitance: Offers large nominal capacitance, ensuring stable operation of the power carrier system.
- Temperature Stability: Good temperature adaptability, ensuring stable operation under different environmental temperatures.
Applications
- Power Carrier Communication Systems: Used in 10kV high-voltage power lines for power data transmission, supporting communication technology.
- Narrow-band Power Carrier Communication: Applied in power carrier communication within the 10KHz ~ 500KHz frequency band.
- Medium-frequency Broadband Power Carrier Communication: Supports power line carrier communication technologies below 12MHz.
- High-frequency Power Carrier Communication Lines: Applied in high-frequency (GHz) power carrier communication lines, providing stable signal transmission.
- Power Industry: Widely used in data transmission and signal coupling in power systems, enhancing the intelligence level of the power system.
| Item | Value |
| Rated Voltage | 10 kVAC |
| Nominal Capacity | 250 pF ~ 32,000 pF |
| Withstand Voltage | 42 kVAC / 2 mins |
| Impulse Voltage | 75 kVAC |
| Tangent of Loss Angle | ≤ 0.01% |
| Filter Band | 10 kHz ~ 5 GHz |
